| No. | Parameter Item | Specification Details |
|---|---|---|
| 4.1 | Typical Capacity | 2230mAh @ 0.2C Discharge |
| 4.2 | Minimum Capacity | 2200mAh @ 0.2C Discharge |
| 4.3 | Nominal Voltage | 3.7V |
| 4.4 | Standard Charge | CC/CV, 0.2C 5A, 4.20V |
| 4.5 | Standard Discharge | CC, 0.2C 5A, 3.00V |
| 4.6 | End-of-charge Voltage | 4.20V ± 0.05V |
| 4.7 | End-of-charge Current | 0.01C 5A (At CV mode) |
| 4.8 | End-of-discharge Voltage | 3.00V |
| 4.9 | Charging Time | 8.0 hours (standard charge) |
| 4.10 | Quick Charge Current | 1000mA (0.5C) |
| 4.11 | Quick Discharge Current | 1000mA |
| 4.12 | Max Discharge Current | 2200mA |
| 4.13 | Initial Impedance | Max: 45mΩ |
| 4.14 | Weight | Approx: 46 ± 1g |
| 4.15 | Operating Temperature | Charging: 0℃~45℃ Discharging: -20℃~60℃ |
| 4.16 | Storage Temperature | -5℃~35℃ |
| 4.17 | Storage Humidity | ≤75% RH |
| 4.18 | Appearance | Without scratch, distortion, contamination, and leakage |
| 4.19 | Standard Environmental Temperature | 23 ± 5℃ |
| 4.20 | Standard Environmental Condition | Humidity: 45-75% RH Atmospheric Pressure: 86-106 KPA |
